| 기능 | 제품사양 | |
|---|---|---|
| Part Size | 3mm ? 203mm (0.125 inches ? 8 inches) | |
| Positioning Accuracy | ±0.038mm (±0.0015 inches) | |
| Weld Force (Programmable) | 500 to 5000 grams,? 200-500 grams (option) | |
| Weld Linear Speed | Up to 38mm (1.5 inches) per second | |
| Rotary Speed | 0 to 28.8°/second ? 720° Max. rotation | |
| HF25 Current Output | 50 to 2400 amps, ±2 amps | |
| HF25 Pulse Width | 0.3 to 2000 milliseconds | |
| Compressed Gas Requirements | 60 psi minimum | |
| Calibration | To NIST standards | |
